KF107DRN180S4詳細信息
KF107DRN180S4
關鍵詞：55KW電動機配減速機_KF107DRN180S4_KF107DV180S4
KF107DRN180S4減速機電機參數：
| 型號 | 減速比 | 功率 | 轉數 | 扭矩 | 重量 | 力矩 | 安全系數 |
| KF107DRN180S4 | 90.96 | 15KW | 16rpm | 8920N.m | 380Kg | 48100N | 0.9 |
| KF107DRN180S4 | 82.61 | 15KW | 18rpm | 8110N.m | 380Kg | 49400N | 1 |
| KF107DRN180S4 | 73.3 | 15KW | 20rpm | 7190N.m | 380Kg | 50400N | 1.1 |
| KF107DRN180S4 | 66.52 | 15KW | 22rpm | 6530N.m | 380Kg | 51000N | 1.25 |
| KF107DRN180S4 | 57.17 | 15KW | 26rpm | 5610N.m | 380Kg | 50600N | 1.45 |
| KF107DRN180S4 | 49.9 | 15KW | 29rpm | 4900N.m | 380Kg | 50000N | 1.6 |
| KF107DRN180S4 | 42.33 | 15KW | 34rpm | 4150N.m | 380Kg | 49100N | 1.75 |
| KF107DRN180S4 | 37 | 15KW | 39rpm | 3630N.m | 380Kg | 48200N | 2 |
| KF107DRN180S4 | 32.69 | 15KW | 45rpm | 3210N.m | 380Kg | 47300N | 2.3 |
| KF107DRN180S4 | 31.28 | 15KW | 47rpm | 3070N.m | 380Kg | 47000N | 2.2 |
| KF107DRN180S4 | 29 | 15KW | 50rpm | 2840N.m | 380Kg | 46400N | 2.5 |
KF107DV180S4減速機電機參數：
| 型號 | 減速比 | 功率 | 轉數 | 扭矩 | 重量 | 力矩 | 安全系數 |
| KF107DV180S4 | 90.96 | 15KW | 16rpm | 8920N.m | 380Kg | 48100N | 0.9 |
| KF107DV180S4 | 82.61 | 15KW | 18rpm | 8110N.m | 380Kg | 49400N | 1 |
| KF107DV180S4 | 73.3 | 15KW | 20rpm | 7190N.m | 380Kg | 50400N | 1.1 |
| KF107DV180S4 | 66.52 | 15KW | 22rpm | 6530N.m | 380Kg | 51000N | 1.25 |
| KF107DV180S4 | 57.17 | 15KW | 26rpm | 5610N.m | 380Kg | 50600N | 1.45 |
| KF107DV180S4 | 49.9 | 15KW | 29rpm | 4900N.m | 380Kg | 50000N | 1.6 |
| KF107DV180S4 | 42.33 | 15KW | 34rpm | 4150N.m | 380Kg | 49100N | 1.75 |
| KF107DV180S4 | 37 | 15KW | 39rpm | 3630N.m | 380Kg | 48200N | 2 |
| KF107DV180S4 | 32.69 | 15KW | 45rpm | 3210N.m | 380Kg | 47300N | 2.3 |
| KF107DV180S4 | 31.28 | 15KW | 47rpm | 3070N.m | 380Kg | 47000N | 2.2 |
| KF107DV180S4 | 29 | 15KW | 50rpm | 2840N.m | 380Kg | 46400N | 2.5 |
KF107DRN180S4減速機類型：
K..DR..底腳安裝斜齒輪—傘齒輪減速電機
KA..B DR..底腳空心軸安裝斜齒輪—傘齒輪減速電機
KV..B DR..底腳花鍵空心軸安裝斜齒輪—傘齒輪減速電機
KH..B DR..底腳空心軸鎖緊盤安裝斜齒輪—傘齒輪減速機
KF..DR..B5法蘭安裝斜齒輪—傘齒輪減速電機
KAF..DR..B5法蘭空心軸安裝斜齒輪—傘齒輪減速電機
KVF..DR..B5法蘭花鍵空心軸安裝斜齒輪—傘齒輪減速電機
KHF..DR..B5法蘭空心軸鎖緊盤安裝斜齒輪—傘齒輪減速電機
KA..DR..空心軸斜齒輪─傘齒輪減速電機
KV..DR..花鍵空心軸安裝斜齒輪—傘齒輪減速電機
KH..DR..空心軸鎖緊盤斜齒輪─傘齒輪減速電機
KT..DR..空心軸安裝斜齒輪—傘齒輪減速電機
KAZ..DR..B14法蘭空心軸安裝斜齒輪─傘齒輪減速電機
KVZ..DR..B14法蘭花鍵空心軸安裝斜齒輪—傘齒輪減速電機
KHZ..DR..B14法蘭空心軸鎖緊盤安裝斜齒輪—傘齒輪減速電機
KF107DRN180S4減速機馬達安裝尺寸圖紙：
KF107DRN180S4減速機生產工廠展示：看廠請?zhí)崆叭祛A(yù)約
大功率減速電機應用案例展示：
關鍵詞:KF系列齒輪減速機與電機_大功率減速電機_大負載減速器_大負載減速機電機_大功率電機減速機_大功率電動機減速機_大負載電動機減速機一套生產廠家
KF系列減速機型號：KF37減速機,KF47減速機,KF57減速機,KF67減速機,KF77減速機,KF87減速機,KF97減速機,KF107減速機,KF127減速機,KF157減速機,KF167減速機,KF187減速機
KF系列減速機可配變頻電機，剎車電機，防爆電機，伺服電機，交流電機，直流電機，三相電機，單相電機 0.12KW-200KW之間
如需工程師幫選型，請加微信13827261050，留言告知工程師參數要求
標簽: 55KW電動機配減速機 KF107DRN180S4 KF107DV180S4
